G Weike LF3015GR- Fiber Laser

  • LF3015GR fiber laser cutting machine can not only cut metal plates, but also metal pipes.
  • It is manufactured with aerospace standards- 3rd Generation Aviation Aluminum Gantry
  • Exchanging Platform
  • The internal structure of the bed adopts the aircraft metal honeycomb structure
  • With a fully enclosed design
  • Fiber laser cutting machine is equipped with German Atlanta rack, Japanese Yaskawa motor, and German Neugart reducer.

More Information

G Weike LF3015GR







Safety and No Pollution

  • With a fully enclosed design;
  • The observation window adopts a European CE Standard laser protective glass;
  • The smoke produced by cutting can be filtrated inside, it’s non-polluting and environmentally friendly;
  • The weight of the machine is 7500kg;



























Dual Use and Cost-saving

LF3015GR fiber laser cutting machine can not only cut metal plates, but also metal pipes. It has many uses and can save the space by more than 50%, which effectively improve productivity.

















The Third Generation Aviation Aluminum Gantry



3rd Generation Aviation Aluminum Gantry

It is manufactured with aerospace standards and formed by 4300 tons press extrusion molding. After aging treatment, its strength can reach 6061 T6 which is the strongest strength of all gantries. Aviation aluminum has many advantages, such as good toughness, light weight, corrosion resistance, anti-oxidation, low density, and greatly increase the processing speed.

















Clamp Design

It adopts an electric clamp design on both sides and it can modulate the center automatically. The diagonal adjustable range is 20-200mm.



















Exchanging Platform

It adopts an up and down exchange platform, and the converter is responsible for controlling the exchanging motor. The machine is able to finish the platform exchanging within 15s.















Fractional Automatic Support Installation

It employs intelligent tube support design, which can solve the deformation problems in the process of long tube cutting.

















The Segmented Rectangular Tube Welded Bed

  • The internal structure of the bed adopts the aircraft metal honeycomb structure, which is welded by a number of rectangular tubes. Stiffeners are arranged inside the tubes to increase the strength and tensile strength of the bed, it also increases the resistance and stability of the guide rail so as to effectively avoid the deformation of the bed.
  •   High strength, stability, tensile strength.





Automatic focus

Without manual focusing

The software automatically adjusts the focusing lens to realize automatic perforating and cutting plates of different thickness. The speed of automatically adjusting focus lens is ten times of the manual adjusting.

Bigger adjustment range

Adjustment range -10 mm~ +10mm, precision 0.01mm, suitable for 0 ~ 20mm different types of plates.

Long service life

Collimator lens and focus lens both have a water-cooling heat sink which reduces the temperature of the cutting head to improve the life of the cutting head.







Transmission and Precision

 German Tech Quality

G·WEIKE fiber laser cutting machine is equipped with German Atlanta rack, Japanese Yaskawa motor, and German Neugart reducer.
The positioning accuracy of the machine tool can be 0.02mm and the cutting acceleration is 1.5G.

  • LASER POWER SOURCE

The laser power source is available with the optional power ratings of

1000W 2000W 3000W 4000W 6000W 8000W (Optional)



  • COMPRESSOR OPTIONS
  • NITROGEN GENERATOR

Cut sample

Compatible tooling & consumables
